Intermolecular Forces formed liquid surface tension. Numbers of tension reflect on liquid sample’s physics and chemical properties; it is one of the most important index to product quality.
Series FT-ZL Automatic Interfacial Tension Tester uses the ring method (GB 6541-86 & ASTM D971) under non-equilibrium conditions to test liquid surface tension (liquid- vapor interface) and mineral oil and water interfacial tension (liquid-liquid interface).
Series FT-ZL uses a microprocessor technology with large-screen color LCD Display and automatic printing test results, with high automation and interactive ability. This tester is the new generation product in many industries such as power plant, petroleum, chemical, pharmaceutical, food, teaching and other industries.
Technical Parameters
|
Display |
Large-screen color LCD Display, English Version |
|
Testing Method |
Platinum Ring method (GB 6541) |
|
Measurement range |
0-200 mN/m |
|
Sensitivity |
0.1 mN/m |
|
Accuracy |
0.1% readings ±0.1 mN/m |
|
Resolution |
0.1 mN/m |
|
Repeatability |
0.3% |
|
Power Supply |
AC220V ±10%, 50Hz ±10% |
|
Power Consumption |
20 W |
|
Ambient temperature |
10～45℃ (25℃ is the best) |
|
Ambient humidity |
≤85% RH |
|
Overall dimensions |
200×300×330(mm) |
|
Weight |
6kg |
Features
1). Auto calibration, auto testing, calculation, results displaying, and results storage under power off.
2). Automatic lift of the lift platform ensures a steady environment and high accuracy.
3). Light and small size, easy to move and operate.
4). Uses electromagnetic force-balance-type transducer, improving the accuracy of the measurement and linearity.
5). Can show current weight values and Equivalent tension value.
6). Can revise the test result automatically.
7). Can storage 255 records max.
8). Built-in micro printer.
